Neutron star 2

Neutron Stars
A neutron star is about 20 km in diameter and has the mass of about 1.4 times that of our Sun. This means that a neutron star is so dense that on Earth, one teaspoonful would weigh a billion tons! Because of its small size and high density, a neutron star possesses a surface gravitational field about 2 x 1011 times that of Earth. Neutron stars can also have magnetic fields a million times stronger than the strongest magnetic fields produced on Earth.

Neutron stars are one of the possible ends for a star. They result from massive stars which have mass greater than 4 to 8 times that of our sun. After these stars have finished burning their nuclear fuel, they undergo a supernova explosion. This explosion blows off the outer layers of a star into a beautiful supernova remnant. The central region of the star collapses under gravity. It collapses so much that protons and electrons combine to form neutrons. Hence the name "neutron star".

Neutron stars may appear in supernova remnants, as isolated objects, or in binary systems. Four neutron stars are thought to have planets. When a neutron star is in a binary system, astronomers are able to measure its mass. From a number of such binaries seen with radio or X-ray telescopes, neutron star masses has been found to be about 1.4 times the mass of the Sun. For binary systems containing an unknown object, this information helps distinguish whether the object is a neutron star or a black hole, since black holes are more massive than neutron stars.

What is a Pulsar and What Makes it Pulse?
Simply put, pulsars are rotating neutron stars. And pulsars pulse because they rotate!

Diagram of a pulsar
A diagram of a pulsar, showing its rotation axis
and its magnetic axis

Pulsars were first discovered in late 1967 by graduate student Jocelyn Bell Burnell as radio sources that blink on and off at a constant frequency. Now we observe the brightest ones at almost every wavelength of light. Pulsars are spinning neutron stars that have jets of particles moving almost at the speed of light streaming out above their magnetic poles. These jets produce very powerful beams of light. For a similar reason that "true north" and "magnetic north" are different on Earth, the magnetic and rotational axes of a pulsar are also misaligned. Therefore, the beams of light from the jets sweep around as the pulsar rotates, just as the spotlight in a lighthouse does. Like a ship in the ocean that sees only regular flashes of light, we see pulsars turn on and off as the beam sweeps over the Earth. Neutron stars for which we see such pulses are called "pulsars", or sometimes "spin-powered pulsars," indicating that the source of energy is the rotation of the neutron star.

A neutron star is formed from the collapsed remnant of a massive star, a Type II, Type Ib, or Type Ic supernova and consists entirely of neutrons. It is a cold star supported by the Pauli exclusion principle repulsion between neutrons. A neutron star is one of the few possible conclusions of stellar evolution.

A typical neutron star has a mass between 1.35 and about 2.1 solar masses, with a corresponding radius between 20 and 10 km — 30,000 to 70,000 times smaller than the Sun. Thus, neutron stars have densities of 8×1013 to 2×1015 g/cm³, about the density of an atomic nucleus.[1]

In general, compact stars of less than 1.44 solar masses, the Chandrasekhar limit, are white dwarfs; above 2 to 3 solar masses (the Tolman-Oppenheimer-Volkoff limit), a Quark star might be created, however this is uncertain. Gravitational collapse will always occur on any star over 5 solar masses, inevitably producing a black hole.

As the core of a massive star is compressed during a supernova, and collapses into a neutron star, it retains most of its angular momentum. Since it has only a tiny fraction of its parent's radius (and therefore its moment of inertia is sharply reduced), a neutron star is formed with very high rotation speed, and then gradually slows down. Neutron stars are known to have rotation periods between about 1.4ms to thirty seconds. The neutron star's compactness also gives it very high surface gravity, 2×1011 to 3×1012 times stronger than that of Earth. One measure of such immense gravity is the fact that neutron stars have an escape velocity of around 150,000 km/s, about 50psl. Matter falling onto the surface of a neutron star would strike the star also at 150,000km/s, and then be crushed under its own weight into a puddle less than an atom thick.


Current understanding of the structure of neutron stars is defined by existing mathematical models. A neutron star is so dense that one teaspoon of its material would weigh 100 million metric tons. On the basis of current models, the matter at the surface of a neutron star is composed of ordinary atomic nuclei as well as electrons. The "atmosphere" of the star is roughly one meter thick, below which one encounters a solid "crust". Proceeding inward, one encounters nuclei with ever increasing numbers of neutrons; such nuclei would quickly decay on Earth, but are kept stable by tremendous pressures. Proceeding deeper, one comes to a point called neutron drip where free neutrons leak out of nuclei. In this region, there are nuclei, free electrons, and free neutrons. The nuclei become smaller and smaller until the core is reached, by definition the point where they disappear altogether. The exact nature of the superdense matter in the core is still not well understood. While this theoretical substance is referred to as neutronium in science fiction and popular literature, the term "neutronium" is rarely used in scientific publications, due to ambiguity over its meaning. The term neutron-degenerate matter is sometimes used, though not universally as the term incorporates assumptions about the nature of neutron star core material. Neutron star core material could be a superfluid mixture of neutrons with a few protons and electrons, or it could incorporate high-energy particles like pions and kaons in addition to neutrons, or it could be composed of strange matter incorporating quarks heavier than up and down quarks, or it could be quark matter not bound into hadrons. (A compact star composed entirely of strange matter would be called a strange star.) However so far observations have neither indicated nor ruled out such exotic states of matter.

Neutron stars are compact objects that are created in the cores of massive stars during supernova explosions. The core of the star collapses, and crushes together every proton with a corresponding electron turning each electron-proton pair into a neutron. The neutrons, however, can often stop the collapse and remain as a neutron star.

Neutron stars are fascinating objects because they are the most dense objects known. They are only about 10 miles in diameter, yet they are more massive than the Sun. One sugar cube of neutron star material weighs about 100 million tons, which is about as much as a mountain.

Like their less massive counterparts, white dwarfs, the heavier a neutron star gets the smaller it gets. Imagine if a 10 pound bag of flour was smaller than a 5 pound bag!

Neutron stars can be observed occasionally, as with Puppis A above, as an extremely small and hot star within a supernova remnant. However, they are more likely to be seen when they are a pulsar or part of an X-ray binary. So, like, how do we get neutron stars?
Neutron stars are believed to form in supernovae such as the one that formed the Crab Nebula (or check out this cool X-ray image of the nebula, from the Chandra X-ray Observatory). The stars that eventually become neutron stars are thought to start out with about 8 to 20-30 times the mass of our sun. These numbers are probably going to change as supernova simulations become more precise, but it appears that for initial masses much less than 8 solar masses the star becomes a white dwarf, whereas for initial masses a lot higher than 20-30 solar masses you get a black hole instead (this may have happened with Supernova 1987A, although detection of neutrinos in the first few seconds of the supernova suggests that at least initially it was a neutron star). In any case, the basic idea is that when the central part of the star fuses its way to iron, it can't go any farther because at low pressures iron 56 has the highest binding energy per nucleon of any element, so fusion or fission of iron 56 requires an energy input. Thus, the iron core just accumulates until it gets to about 1.4 solar masses (the "Chandrasekhar mass"), at which point the electron degeneracy pressure that had been supporting it against gravity gives up the ghost and collapses inward.

At the very high pressures involved in this collapse, it is energetically favorable to combine protons and electrons to form neutrons plus neutrinos. The neutrinos escape after scattering a bit and helping the supernova happen, and the neutrons settle down to become a neutron star, with neutron degeneracy managing to oppose gravity. Since the supernova rate is around 1 per 30 years, and because most supernovae probably make neutron stars instead of black holes, in the 10 billion year lifetime of the galaxy there have probably been 10^8 to 10^9 neutron stars formed. One other way, maybe, of forming neutron stars is to have a white dwarf accrete enough mass to push over the Chandrasekhar mass, causing a collapse. This is speculative, though, so I won't talk about it further.

The guts of a neutron star
We'll talk about neutron star evolution in a bit, but let's say you take your run of the mill mature neutron star, which has recovered from its birth trauma. What is its structure like? First, the typical mass of a neutron star is about 1.4 solar masses, and the radius is probably about 10 km. By the way, the "mass" here is the gravitational mass (i.e., what you'd put into Kepler's laws for a satellite orbiting far away). This is distinct from the baryonic mass, which is what you'd get if you took every particle from a neutron star and weighed it on a distant scale. Because the gravitational redshift of a neutron star is so great, the gravitational mass is about 20% lower than the baryonic mass.

Anyway, imagine starting at the surface of a neutron star and burrowing your way down. The surface gravity is about 10^11 times Earth's, and the magnetic field is about 10^12 Gauss, which is enough to completely mess up atomic structure: for example, the ground state binding energy of hydrogen rises to 160 eV in a 10^12 Gauss field, versus 13.6 eV in no field. In the atmosphere and upper crust, you have lots of nuclei, so it isn't primarily neutrons yet. At the top of the crust, the nuclei are mostly iron 56 and lighter elements, but deeper down the pressure is high enough that the equilibrium atomic weights rise, so you might find Z=40, A=120 elements eventually. At densities of 10^6 g/cm^3 the electrons become degenerate, meaning that electrical and thermal conductivities are huge because the electrons can travel great distances before interacting.

Deeper yet, at a density around 4x10^11 g/cm^3, you reach the "neutron drip" layer. At this layer, it becomes energetically favorable for neutrons to float out of the nuclei and move freely around, so the neutrons "drip" out. Even further down, you mainly have free neutrons, with a 5%-10% sprinkling of protons and electrons. As the density increases, you find what has been dubbed the "pasta-antipasta" sequence. At relatively low (about 10^12 g/cm^3) densities, the nucleons are spread out like meatballs that are relatively far from each other. At higher densities, the nucleons merge to form spaghetti-like strands, and at even higher densities the nucleons look like sheets (such as lasagna). Increasing the density further brings a reversal of the above sequence, where you mainly have nucleons but the holes form (in order of increasing density) anti-lasagna, anti-spaghetti, and anti-meatballs (also called Swiss cheese).

When the density exceeds the nuclear density 2.8x10^14 g/cm^3 by a factor of 2 or 3, really exotic stuff might be able to form, like pion condensates, lambda hyperons, delta isobars, and quark-gluon plasmas. Here's a gorgeous figure (from http://www.astroscu.unam.mx/neutrones/NS-picture/NStar/NStar-I.gif) that shows the structure of a neutron star:
